• Length:28' 4"
• Beam: 9' 10"
• Bottom width: 7' 9"
• Max. recommended HP: 700 HP
• Fuel capacity: 228 gal.
• Max. person capacity: 13 persons
• Max. person weight: 5490 lbs.
• Max. person, motor & gear weight: 5791 lbs.
• Interior depth: 33"
• Transom height at center line: 30"
• Deadrise: 21 degrees
• Draft: 21"
• Dry weight: 7270 lbs.
• Average hull weight: 6000 lbs.
• Average package weight: 9800 lbs.
• Package height w/T-top or hardtop: 12' 4"
• Storage length: 37' 10"

Certification & Safety

• Backed by the MAKO® Assurance 5+Life—the best factory warranty in the business
• NMMA® certified
• Factory leak tested for hull, plumbing & fitting integrity
• Stainless steel hardware & fasteners for corrosion resistance
• CorrosionX stainless spray treatment included
• Horn

Console

• Custom anodized aluminum tilt steering wheel w/knob
• Dual-cylinder hydraulic steering
• Binnacle-mounted motor control
• Gauge panel w/digital gauges
• Trim tab switches w/position indicator lights & auto retract
• Powdercoated aluminum battery switch panel w/labels, main power shutoff, emergency parallel switch, removable knobs & voltage sensing relays (VSR)
• Switch panel w/manual reset circuit breakers & illuminated switches
• Recessed switch panel w/circuit breakers & motor ignition switches
• Easy access to helm electronics, instruments & switches
• Oversized forward-console seat w/storage compartment & 2 drink holders
• Integrated full-width fiberglass footrest w/non-skid surface
• Tempered safety glass windscreen w/aluminum frame
• Easy-access battery storage
• Marine-grade tinned wiring w/submersible connectors
• Extra-large electronics mounting surface
• 2 console drink holders
• 12V DC outlet

Construction & Exterior

• 100% composite construction
• Coosa® Bluewater 100% composite transom core
• Heavy-duty, fiberglass-encapsulated transom w/2" (5.08 cm) fiberglass-impregnated, high-density composite core
• Hull/deck joint chemically sealed & bonded 360° & mechanically fastened every 6" (15.24 cm) w/316 stainless steel fasteners
• 1-piece molded fiberglass stringer grid w/integrated transom knee supports & gelcoat finish
• Closed-cell, foam-injected stringer grid for USCG-approved flotation
• Premium marine-grade stainless steel hardware
• Heavy-duty rub rail w/stainless steel insert
• Closed-molded hatch covers w/finished undersides & integrated gaskets
• Aluminum backing plates for cleats, chocks & hinges
• Recessed, pull-out, telescoping boarding ladder
• MAKO® Bone White gelcoat

Electrical, Mechanical & Plumbing Systems

• Aluminum main fuel tank w/4 baffles
• 2 automatic 2,000 GPH (7,570 LPH) bilge pumps
• 1,600 GPH (6,057 LPH) & 1,100 GPH (4,164 LPH) baitwell pumps
• Pressurized raw water washdown pump
• High-speed raw water intake
• Pressurized freshwater pump
• 13-gal. (49 L) freshwater tank for sinks & shower
• USCG-compliant navigation lights
• 2 cockpit courtesy lights & 1 head light
• 1 cranking battery per outboard
• Marelon® corrosion-free seacocks on all below-water thru-hull fittings
• Labeled, tinned-copper wiring for easy maintenance & protection in a marine environment
• Pre-wired for optional stereo system & speakers
• Pre-wired for optional anchor windlass

Head

• Gelcoat-finished surface, sink, wiring access hatches, battery switch panel, battery access & 6' (1.8 m) head room
• Sink w/faucet & on-demand freshwater
• Portlight in head door

Interior

• NEW 2-tone high-density marine-grade vinyl upholstery w/stain-resistant coating & composite substrates on seats
• Anchor locker w/protective inner liner
• Foredeck dodger mounting boss
• Port & starboard forward seats w/99-qt (94 L) fishboxes w/gravity overboard drainage
• 470-qt. (445 L) center bow in-deck storage compartment w/drain
• Low profile brushed anodized aluminum bow rails
• Self-bailing cockpit w/gutters, oversized drains & transom valves
• 3 port & 3 starboard gunnel-mounted rod holders
• Port & starboard under-gunnel rod racks for 6 rods up to 7' (2.1 m) long
• Port & starboard tilt-out storage bins
• Freshwater shower w/pull-out spray head
• 290-qt. (274 L) insulated port & starboard aft in-deck fishboxes w/Gulper macerator & overboard discharge
• Molded non-skid surfaces throughout
• Bilge access hatch
• Walk-thru transom w/latching door
• Port & starboard molded-in swim platforms
• Port & starboard aft coaming bolsters
• 2 bow drink holders

Leaning Post

• Fiberglass leaning post
• Backrest
• Flip-up cushion
• Storage below
• Bait prep station w/freshwater sink, removable cutting board, 50-gal. (189.27 L) aerated anti-slosh baitwell & tackle storage

Optional Trailer

• OPTIONAL aluminum triple-axle trailer available.
• NMMA® certified.
• DOT approved.
• Triple-axle brakes.
• 15" (38.1 cm) radial tires w/galvanized V5 wheels.
• Oil bath hubs.
• Torsion-axle suspension.
• Heavy-duty winch w/nylon strap & safety strap.
• Stainless steel hardware.
• Galvanized steel components.
• LED lighting.
• LED marker lights.
• PVC loading guides.
• Galvanized fenders.

Performance

• Legendary dry-riding MAKO® hull
• Aggressive deep V hull design
• Performance lifting strakes
• Recessed electric trim tabs
• Factory-matched stainless steel propellers

T-Top or Hardtop

• Outrigger-ready fiberglass hardtop w/5 rod holders, electronics box & 3 spreader lights (1 fore, 2 aft)
• .25" (.64 cm) in-deck aluminum backing-plate reinforcement for hardtop frame
• .25" (.64 cm) aluminum backing-plate reinforcement for hardtop
